1

Power supply unit (PSU 1)

AC 800 W.
Both power supplies should be plugged in to power to provide redundancy.

2

PCIe expansion card riser (slot 1)

The expansion card riser enables you to connect PCI Express expansion cards. The capture adapter is installed in this PCIe expansion card riser, specifically slot 1 for x16.

3

PCIe expansion card riser (slot 2)

The expansion card riser enables you to connect PCI Express expansion cards.

4

USB 2.0 port (1)

Use the USB 2.0 port to connect USB devices to the system. These ports are 4-pin, USB 2.0-compliant.

5

Power supply unit (PSU 2)

AC 800 W.
Both power supplies should be plugged in to power to provide redundancy.

6

VGA port

Use the VGA port to connect a display to the system.

7

USB 3.0 port (1)

Use the USB 3.0 port to connect USB devices to the system. These ports are 4-pin, USB 3.0-compliant.

8

iDRAC dedicated port

This port enables you to remotely access iDRAC. iDRAC is very useful for remote management and direct access of the appliance.

9

System identification button

The System Identification (ID) button is available on the back of the system. Press the button to identify a system in a rack by turning on the system ID button. You can also use the system ID button to reset iDRAC and to access BIOS using the step through mode.

10

OCP NIC port (optional)

This port supports OCP 3.0. The NIC ports are integrated on the OCP card which is connected to the system board.

11

NIC port (2)

The NIC ports are embedded on the LOM card that is connected to the system board.

12

BOSS S2 card (optional)

This slot supports the BOSS S2 module.
